UltraMix® 7500 Series Pantone® Color System consists of 19 non-phthalate, high performance colors, formulated for ultra high speed wet-on-wet automatic printing. Create special or standard colors by using International Coatings’ UltraMix®, Pantone® color matching software, either online or on the desktop version. 7500 Series Colors are FlexCure™ and can cure as low as 275ºF (135ºC). Well suited for fine detail and halftone printing using finer mesh counts.
Colors:
7503 Yellow
7505 Scarlet
7507 Red
7509 Violet
7511 Marine Blue
7513 Blue A (GS)
7515 Blue B (RS) | 7517 Green
7536 Black
7538 Mixing White
7519 Fluorescent Magenta
7521 Fluorescent Violet
7523 Fluorescent Blue | 7525 Fluorescent Green
7527 Fluorescent Yellow
7529 Fluorescent Lemon
7531 Fluorescent Orange
7533 Fluorescent Pink
7535 Fluorescent Red |
Recommended Fabrics:
100% cotton or cotton/polyester blends. Use an underbase for dark fabrics.
Recommended Fabrics:
100% cotton or cotton/polyester blends. Use an underbase for dark fabrics.
Ink Application:
Colors should be printed without any modifications. If thinning is required, use 1099 LB Lo-Bleed Reducer (1% to 5% by weight).
Screen Mesh:
110 to 305 Monofilament.
Emulsion:
Any direct or indirect plastisol emulsion. Use 35 to 70 micron capillary film for best results.
Squeegee:
60-70 Durometer: Sharp Edge.
60/90/60 or 70/90/70 Triple Durometer: Sharp Edge
Drying Temperatures:
275ºF - 325°F entire ink film*
*It is always recommended to test dryer temperatures and wash test the printed product before and during a production run.
Clean Up:
Any Environmentally friendly plastisol screen wash.
Storage of Ink Containers:
Keep indoors and store in a cool area. Recommended storage at 65º F to
90º F (18º C to 32º C). Avoid storage in direct sunlight or in extreme
temperature conditions.
